All dimensions in mm unless otherwise specified |
|
|
|
|
|
| Bore Size |
A |
B |
C |
D |
E |
EE BSP |
F |
G Ø |
H Ø |
I |
J |
K tdD's |
L |
M |
N |
P tdD |
R |
| 125mm |
172.0 |
51 |
12 |
64 |
47.0 |
3/8" |
64.0 |
50.0 |
35 |
80.0 |
76 |
M27 x 2P |
28.0 |
108 |
140 |
M12 x 1.75P |
236 |
| 150mm |
176.5 |
51 |
8 |
68 |
42.5 |
1/2" |
59.5 |
50.0 |
35 |
75.8 |
85 |
M27 x 2P |
32.5 |
130 |
165 |
M16 x 2P |
236 |
| 8" |
210.0 |
55 |
12 |
72 |
48.0 |
3/4" |
63.0 |
64.0 |
45 |
81.0 |
111 |
M38 x 2P |
35.0 |
168 |
216 |
M20 x 2.5P |
273 |
| 10" |
248.0 |
76 |
10 |
165 |
22.0 |
3/4" |
48.0 |
88.5 |
57 |
76.0 |
144 |
M50 x 2P |
48.0 |
210 |
267 |
M24 x 3P |
296 |
| 12" |
289.0 |
76 |
13 |
183 |
28.0 |
1" |
60.0 |
95.0 |
57 |
89.0 |
171 |
M50 x 2P |
54.5 |
246 |
325 |
M24 x 3P |
349 |
| 14" |
289.0 |
76 |
13 |
183 |
28.0 |
1" |
60.0 |
95.0 |
57 |
89.0 |
171 |
M50 x 2P |
54.5 |
292 |
375 |
M24 x 3P |
349 |
|
|
|
