All dimensions in mm unless otherwise specified |
|
|
|
|
|
| Piston Dia. mm |
A |
AB Ø |
AO |
AU |
B1 SQ |
B2 |
B3 |
B5 |
B6 |
C1 |
CE |
CK Ø |
CM |
D1 Ø |
D11 Ø |
D12 Ø |
E3 |
ER |
FB Ø |
G1 |
G2 |
G3 |
H1 |
| Ø 12 |
12 |
5.5 |
6 |
14 |
12 |
16.0 |
3.2 |
8 |
25 |
20 |
24 |
6 |
6 |
10 |
6 |
6 |
12.1 |
7 |
5.5 |
13 |
15 |
25 |
4 |
| Ø 16 |
12 |
5.5 |
6 |
14 |
12 |
16.0 |
3.2 |
8 |
25 |
20 |
24 |
6 |
6 |
10 |
6 |
6 |
12.1 |
7 |
5.5 |
13 |
15 |
25 |
4 |
| Ø 20 |
16 |
6.5 |
8 |
17 |
16 |
21.5 |
4.0 |
8 |
30 |
25 |
32 |
8 |
8 |
14 |
8 |
6 |
16.1 |
10 |
6.5 |
16 |
20 |
32 |
5 |
| Ø 25 |
20 |
6.5 |
8 |
17 |
20 |
26.0 |
5.0 |
8 |
30 |
25 |
40 |
10 |
10 |
18 |
8 |
6 |
16.1 |
12 |
6.5 |
16 |
20 |
32 |
5 |
| Piston Dia. mm |
H5 |
H6 |
H7 |
H8 |
KK |
L13 |
L14 |
LE |
NH |
R1 |
R2 |
SA |
SW |
TF |
TR |
UF |
UR |
US |
W |
XA |
XS |
ZF |
| Ø 12 |
27 |
3 |
38 |
58 |
M6 x 1P |
18 |
76.0 |
12 |
20 |
13 |
7 |
78.0 |
10 |
40 |
32 |
50 |
30 |
42 |
18 |
86.0 |
32 |
76.0 |
| Ø 16 |
27 |
3 |
38 |
58 |
M6 x 1P |
18 |
82.0 |
12 |
20 |
13 |
7 |
84.0 |
10 |
40 |
32 |
50 |
30 |
42 |
18 |
92.0 |
32 |
82.0 |
| Ø 20 |
30 |
4 |
46 |
66 |
M8 x 1.25 |
20 |
96.5 |
16 |
25 |
20 |
10 |
102.5 |
13 |
50 |
40 |
66 |
40 |
54 |
19 |
109.5 |
37 |
97.5 |
| Ø 25 |
30 |
4 |
46 |
66 |
M10 x 1.25 |
24 |
101.5 |
20 |
25 |
20 |
10 |
103.5 |
17 |
50 |
40 |
66 |
40 |
54 |
23 |
114.5 |
41 |
102.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
